Drahtseilklemmen ähnl. DIN 741, galvanisch verzinkt
Drahtseilklemmen für untergeordnete Zwecke
| Art. Nr. | Ngr. | Seil-Ø mm | A mm | B1 mm | B2 mm | G | H1 mm | H2 mm | Gewicht per 100 St. kg |
| 20030 | 1/8" | 3 | 12 | 4 | 10 | M 4 | 20 | 10 | 0,7 |
| 20050 | 3/16" | 5 | 13 | 6 | 11 | M 5 | 24 | 10 | 1,5 |
| 20060 | 1/4" | 6 | 15 | 8 | 12 | M 5 | 28 | 11 | 1,9 |
| 20080 | 5/16" | 8 | 19 | 9 | 14 | M 6 | 34 | 15 | 3,2 |
| 20100 | 3/8" | 10 | 22 | 11 | 18 | M 8 | 42 | 17 | 6,6 |
| 20110 | 7/16" | 11 | 22 | 12 | 19 | M 8 | 44 | 18 | 7,1 |
| 20130 | 1/2" | 13 | 30 | 14 | 23 | M 10 | 55 | 21 | 12,5 |
| 20140 | 9/16" | 14 | 30 | 15 | 23 | M 10 | 57 | 22 | 14,0 |
| 20160 | 5/8" | 16 | 33 | 17 | 26 | M 12 | 63 | 26 | 20,5 |
| 20190 | 3/4" | 19 | 38 | 20 | 29 | M 12 | 75 | 30 | 30,8 |
| 20220 | 7/8" | 22 | 44 | 23 | 33 | M 12 | 85 | 34 | 35,7 |
| 20260 | 1" | 26 | 45 | 27 | 35 | M 16 | 95 | 37 | 56,9 |
| 20300 | 1.1/8" | 30 | 50 | 32 | 37 | M 16 | 110 | 43 | 61,8 |
| 20340 | 1.1/4" | 34 | 55 | 36 | 42 | M 16 | 120 | 50 | 86,8 |
| 20400 | 1.1/2" | 40 | 60 | 42 | 45 | M 16 | 140 | 55 | 109,0 |
| 20450 | 1.3/4" | 45 | 65 | 47 | 49 | M 18 | 165 | 65 | 148,0 |
| 20500 | 2" | 50 | 67 | 54 | 51 | M 18 | 170 | 67 | 195,0 |
Drahtseilklemmen ähnl. EN 13411-5 A, galvanisch verzinkt (gelb)
(vormals DIN 1142)
Die Größe 13 entspricht nicht der EN 13411-5, sie entspricht der DIN 1142.
| Art. Nr. | Ngr. | Seil-Ø mm | A mm | B1 mm | B2 mm | G | H1 mm | H2 mm | Gewicht per 100 St. kg |
| 21050 | 5 | 5 | 13 | 12 | 13 | M 5 | 25 | 13 | 2,1 |
| 21065 | 6.5 | 6.5 | 14 | 14 | 16 | M 6 | 32 | 14 | 4,0 |
| 21080 | 8 | 8 | 18 | 18 | 20 | M 8 | 41 | 18 | 8,2 |
| 21100 | 10 | 10 | 21 | 20 | 20 | M 8 | 46 | 21 | 9,2 |
| 21120 | 12 | 12 | 25 | 24 | 24 | M 10 | 56 | 25 | 24,0 |
| 21130 | 13 | 13 | 30 | 27 | 28 | M 12 | 64 | 29 | 27,5 |
| 21140 | 14 | 14 | 30 | 28 | 28 | M 12 | 66 | 30 | 28,0 |
| 21160 | 16 | 16 | 35 | 32 | 32 | M 14 | 76 | 35 | 43,0 |
| 21190 | 19 | 19 | 40 | 36 | 32 | M 14 | 83 | 40 | 49,0 |
| 21220 | 22 | 22 | 44 | 40 | 34 | M 16 | 96 | 44 | 68,0 |
| 21260 | 26 | 26 | 51 | 46 | 38 | M 20 | 118 | 51 | 117,0 |
| 21300 | 30 | 30 | 59 | 54 | 41 | M20 | 131 | 59 | 140,0 |
| 21340 | 34 | 34 | 67 | 60 | 45 | M 22 | 150 | 67 | 213,0 |
| 21400 | 40 | 40 | 77 | 68 | 49 | M 24 | 167 | 77 | 268,0 |
ALU-Pressklemmen gem. EN 13411-3 A
Die Art. 27010, 27015 und 27020 entsprechen nicht der EN 13411-3.
Weitere Größen auf Anfrage.
| Art. Nr. | Ngr. | Seil-Ø mm | i. Weite mm | i. Höhe mm | g. Länge mm | Wandstärke mm | Gewicht per 100 St. kg |
| 27010 | 1 | 1 | 1.2 | 2,4 | 5 | 0,65 | 0,0075 |
| 27015 | 1.5 | 1.5 | 1.7 | 3,4 | 6 | 0,75 | 0,0140 |
| 27020 | 2 | 2 | 2.4 | 4,8 | 7 | 0,85 | 0,0245 |
| 27025 | 2.5 | 2.5 | 2.7 | 5,4 | 9 | 1,05 | 0,0450 |
| 27030 | 3 | 3 | 3.3 | 6,6 | 11 | 1,25 | 0,0850 |
| 27035 | 3.5 | 3.5 | 3.8 | 7,6 | 12 | 1,45 | 0,1350 |
| 27040 | 4 | 4 | 4.4 | 8,8 | 14 | 1,70 | 0,1900 |
| 27045 | 4.5 | 4.5 | 4.9 | 9,8 | 16 | 1,90 | 0,2500 |
| 27050 | 5 | 5 | 5.5 | 11,0 | 18 | 2,10 | 0,3700 |
| 27060 | 6 | 6 | 6.6 | 13,2 | 21 | 2,50 | 0,6000 |
| 27065 | 6.5 | 6.5 | 7.2 | 14,4 | 23 | 2,70 | 0,8000 |
| 27070 | 7 | 7 | 7.8 | 15,6 | 25 | 2,90 | 0,9600 |
| 27080 | 8 | 8 | 8.8 | 17,6 | 28 | 3,30 | 1,4000 |
| 27090 | 9 | 9 | 9.9 | 19,8 | 32 | 3,70 | 2,0000 |
| 27100 | 10 | 10 | 10.9 | 21,8 | 35 | 4,10 | 2,7000 |
| 27110 | 11 | 11 | 12.1 | 24,2 | 39 | 4,50 | 3,7000 |
| 27120 | 12 | 12 | 13.2 | 26,4 | 42 | 4,90 | 4,6500 |
| 27130 | 13 | 13 | 14.2 | 28,4 | 46 | 5,40 | 6,0000 |
| 27140 | 14 | 14 | 15.3 | 30,6 | 49 | 5,80 | 7,4000 |
| 27160 | 16 | 16 | 17.5 | 35,0 | 56 | 6,70 | 11,1000 |
| 27180 | 18 | 18 | 19.6 | 39,2 | 63 | 7,60 | 16,0000 |
| 27200 | 20 | 20 | 21.7 | 43,4 | 70 | 8,40 | 21,9000 |
| 27220 | 22 | 22 | 24.3 | 48,6 | 77 | 9,20 | 29,1000 |
| 27240 | 24 | 24 | 26.4 | 52,8 | 84 | 10,00 | 37,5000 |
| 27260 | 26 | 26 | 28.5 | 57,0 | 91 | 10,90 | 47,9000 |
| 27280 | 28 | 28 | 31,0 | 62,0 | 98 | 11,70 | 60,0000 |
| 27300 | 30 | 30 | 33,0 | 66,0 | 105 | 12,00 | 74,0000 |
Maße und Gewichtangaben annähernd, Änderungen vorbehalten
